Installing Soft Touch Resonators

The parts included in rthe Kit:

1. Two Ceramic Reflectors

2. Two Stainless steel spacers
3. A stainless steel shim for the top of the reflector

Once the parts to be replaced have been removed from the chamber and the inside of the chamber has been cleaned, place a reflector and the two spacers as shown in the image below. The spacers have only one position, it is not possible to place them differently inside the chamber

Then, place the Yag Rod again, remember that it must be in the same position it was in before removing it from the chambre to preserve the alignment of the Laser. Place the lamp and the flow plate.

Now, place the second ceramic reflector on the top. Make sure the Flow Plate is upright in the slot of both reflectors. Place the Shim above the Reflector. It should have a slight upward curve in the middle so that it makes contact with the plunger
